Made in Australia – Designed and built for some of the toughest environments on earth.
Contrl® optic for optimum light pattern
Available with either 4000k or 5700k Colour Temperature
Match your rim colour to your vehicle or 24ct Gold Plated rim with black brackets
5 Year Warranty – Peace of mind
A wiring harness and anti-theft nuts are supplied free of charge when you buy 2 lamps
Optional Rim Colour Matching (colours shown are examples only)
Includes clear protective lens cover with every lamp
The Nitro 80 Maxx is an excellent all-rounder, giving a balance of width and distance. Equipped 19 LumiLED LED’s Contrl® optic, the 80W Maxx delivers exceptional output for its size. The proven housing design and 4mm stainless steel bracket ensure that wherever you’re going, your Maxx’s will get you home safely.
Engineered & Built in Australia the 80W NITRO LED driving lamp utilises 19 LumiLED LED’s producing over 6830 raw lumens per Lamp.
All Nitro lights come complete with an easy adjust mounting bracket, clear lens covers, wiring harness and anti-theft nuts.
Beam Pattern
| SPECIFICATIONS |
Nitro 80 Maxx |
| Wattage |
80 Watt |
| Light Source |
19 LumiLED LED’s |
| Light Output – Raw |
8625 Lumens/lamp |
| Light Output – Effective |
6840 Lumens/lamp |
| Voltage |
9V-36V |
| Current Draw |
4.5A @ 13.5V |
| Operating Temperature |
-40°C to +80°C |
| Waterproof rating |
IP68 |
| Connector Type |
Deutsch DT 2 Pin |
| Housing |
Die Cast Alloy |
| Lens Construction |
Polycarbonate |
| Bracket |
4mm Stainless Steel |
| Beam Colour |
4000K or 5700K |
| Lifespan |
50’000 Hours |
| Diameter |
180mm |
| Net Weight |
1.3kg |
| Beams Available |
Widr® |
| Warranty |
5 Years |
| Harness and anti-theft nuts included |
Yes |
| Outer Lens Cover Included Free |
Yes |
4000k vs 5700k Colour Temperature
